Sadiki Metals, located in Kinshasa, Congo, has established itself as a top-notch manufacturer and supplier of high-quality aluminum products. The company takes great pride in offering durable and precision-engineered Aluminium 5083 bars and rods that adhere to international standards. With state-of-the-art production facilities and strict quality control measures, Sadiki Metals guarantees consistency, reliability, and outstanding performance in every item they produce. Catering to a wide range of industries, the company blends technical know-how with exceptional customer service. Whether it’s for local projects or international endeavors, Sadiki Metals is recognized as a dependable partner, delivering aluminum solutions that provide strength, corrosion resistance, and versatility for even the most demanding applications.
Aluminium 5083 bars and rods are primarily made from aluminum alloyed with magnesium (about 4–4.9%), along with small amounts of manganese (0.4–1%) and traces of chromium. This unique composition significantly boosts corrosion resistance, particularly in marine and industrial settings. On the mechanical side, Aluminium 5083 showcases impressive strength, with a tensile strength ranging from 228 to 317 MPa and a yield strength between 125 and 215 MPa, depending on the temper. The material is not only highly ductile and weldable but also boasts good fatigue resistance, making it perfect for structural applications. Its lightweight nature combined with durability ensures top-notch performance even in harsh conditions.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Weight% | Al | Si | Fe | Cu | Mn | Cr | Mg | Ti | Zn | Other Each | Others Total |
| 5083 | Bal | 0.40 max | 0.40 max | 0.10 max | 0.40 / 1.0 | 0.05 / 0.25 | 4.0 / 4.90 | 0.15 max | 0.25 max | 0.05 max | 0.15 max |
| Properties | Proof Stress | Tensile Strength | Hardness Brinell | Elongation |
| Metric | 125 Min MPa | 275 – 350 MPa | 75 HB | 12 Min % |
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlMg4,5Mn0,7 | AG4,5MC | 3.3547 | A95083 | AlMg4,5Mn0,7 | 5083 | AlMg4,5Mn |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 5083 bars are fully recyclable. Recycling preserves the material's properties, reduces energy consumption, and minimizes environmental impact, making it an eco-friendly choice for sustainable manufacturing.
To maintain Aluminium 5083 bars, regularly clean them with mild detergent and water to prevent corrosion. Avoid abrasive materials, and apply protective coatings if exposed to harsh environments for enhanced durability.
When installing Aluminium 5083 bars and rods, consider proper welding techniques, corrosion protection, accurate measurements, compatibility with other materials, and ensuring proper handling to avoid surface damage or distortion.
Aluminium 5083 bars and rods find extensive use in industries that demand high strength and corrosion resistance. They are crucial in marine applications, such as shipbuilding, offshore platforms, and docks, thanks to their ability to withstand saltwater corrosion. This alloy is also utilized in transportation, including automotive and railway components, providing a lightweight yet robust alternative. In construction, it serves in pressure vessels, storage tanks, and pipelines, while the aerospace sector employs it for aircraft structural parts. Moreover, its excellent formability and weldability make it a versatile choice across various applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Sadiki Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Kinshasa, Congo
