Nestled in the heart of Kinshasa, Congo, Sadiki Metals has built a reputation as a trusted local partner for demanding industrial needs. We take pride in our specialized production of Hastelloy C276 forgings, delivering components that stand up to the most aggressive environments. Our focus is on providing reliable, high-integrity solutions that support the robust growth of regional industries, ensuring that our clients have access to world-class materials backed by local expertise and a commitment to quality that you can count on.
The strength of our Hastelloy C276 forgings lies in their sophisticated nickel-molybdenum-chromium composition, which is specifically designed to resist pitting and cracking from chlorides. This alloy maintains exceptional mechanical properties, including high tensile strength and impressive toughness, even after exposure to extreme temperatures. It’s this combination of a resilient chemical makeup and dependable physical characteristics that makes our forgings a cornerstone for equipment that simply cannot afford to fail.
Specifications ASTM B564 / ASME SB564
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
Grades Hastelloy C276 Forging UNS (N10276), DIN (2.4819)
ISO 9725
| Grade | Ni | C | Mo | Mn | Si | Fe | P | S | Co | Cr | W | V |
| Hastelloy C276 | Balance | 0.01 max | 15–17 | 1.0 max | 0.08 max | 4–7 | 0.04 max | 0.03 max | 2.5 max | 14.5–16.5 | 3–4.5 | 0.35 max |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | OR | GOST |
| Hastelloy C276 | N10276 | 2.4819 | – | NiMo16Cr15W | NW 0276 | ЭП760 | ХН65МВУ |
Post-forging operations for Hastelloy C276 include heat treatment (such as annealing) to relieve stresses and improve mechanical properties, followed by surface finishing (like pickling or grinding) to remove oxides and enhance corrosion resistance.
To determine if Hastelloy C276 forgings meet your needs, assess their chemical composition, mechanical properties, and resistance to corrosion under the specific conditions of your application. Conduct testing such as tensile, impact, and corrosion tests for confirmation.
The ideal temperature range for forging Hastelloy C276 is between 1,900°F and 2,200°F (1,038°C to 1,204°C). This ensures proper deformation without compromising material properties.
The real-world value of these forgings is seen in their critical applications, particularly throughout the chemical processing and pollution control industries. They are the preferred choice for constructing pumps, valves, and reactor vessels that handle harsh acids and other corrosive media. From withstanding the demanding conditions of flue gas desulfurization systems to ensuring the safe transport of aggressive chemicals, our Hastelloy C276 components provide the durable, long-lasting performance that keeps essential operations running smoothly and safely.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
