Sadiki Metals, based in Kinshasa, Congo, stands out as a top manufacturer and supplier of Inconel 617 Bars and Rods. These high-performance products are specifically designed to thrive in extreme high-temperature and corrosive environments. Crafted from premium-grade Inconel 617 alloy through advanced metallurgical techniques, these bars and rods offer remarkable strength, durability, and precise dimensions. Sadiki Metals is committed to upholding international quality standards, ensuring that their products deliver reliable and consistent performance. The Inconel 617 Bars and Rods find extensive applications in industries like aerospace, power generation, and chemical processing, where they excel in resisting oxidation, creep, and thermal fatigue, especially in demanding conditions that require long-term stability.
The composition of Inconel 617 Bars and Rods primarily includes nickel, chromium, and cobalt, with small amounts of molybdenum and iron added to boost high-temperature strength and oxidation resistance. This unique blend results in exceptional tensile and yield strength, creep resistance, and hardness, all while maintaining impressive ductility and fatigue resistance at elevated temperatures. Mechanically, Inconel 617 holds up well under intense thermal and mechanical stress, providing outstanding resistance to oxidation, corrosion, and scaling. Its combination of strength, stability, and workability makes it a perfect fit for critical applications in tough industrial and aerospace settings.
| Standards | ASTM B166, ASME SB 166, AMS 5887 |
|---|---|
| Specifications | DIN, EN, ASTM, JIS, ASME, BS, AISI |
| 617 Inconel Round Bars size | Diameter: 3-~800mm |
| Inconel 617 Flat Bars size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Inconel 617 Angle Bars size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Inconel 617 Channel Bars | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Alloy 617 Rectangular Bars Section | 3.0 to 12.0mm thickness |
| Inconel 617 Billet Size | 1/2 to 495mm Diameter |
| Inconel 617 Rectangle Bar Size | 33 x 30mm to 295 x 1066mm |
| Inconel 617 Hex Bar size | 2-100mm A/F |
| Inconel 617 Hollow Bars | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Diameter | 20mm, 30mm, 50mm, 80mm, 100mm, 150mm, 200mm, 500mm |
| Length | 1m-12m or as required |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish | hot rolled annealed, peeled, Bright, hot-worked and cold-worked rod and bar, centreless ground, Centreless Ground and Black, Polish, Cold Rolled (CR), hot rolled ( R), smooth turned, Cold (bright) drawn, Grinding, slit rolled edge, Rough Turned. |
| Surface | Hot Rolled Pickled, Bright, Sand Blasting Finished, Cold Drawn, Hairline,Polished |
| Condition | Hardened & tempered, annealed |
| Technique | Cold Drawn, Hot Rolled, Forged Round Bars, Cold Rolled, Rod |
| Processing | Bars cutting to 650mm |
| Form | Rod, Round, Channel Bars, T-Bars, Flat Bars, Precision Ground Bars, Blocks, Square, Round Rod, Triangle, Hollow, Rectangle, Threaded, Hex (A/F), Profiles, Half Round Bars, Ingot, Billet, I/H Bars, Forging etc. |
| STANDARD | WERKSTOFF NR. | UNS |
| Inconel 617 | 2.4663 | N06617 |
| Grade | Ni | Cr | Fe | C | Mn | S | Mo | Si | Co |
| Inconel 617 | 48.85 – 62 | 20 – 24.0 | Balance | ≤ 0.15 | ≤ 1 | – | 8 – 10 | ≤ 1 | 10-15 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.3g/cm³ | 1363°C | ≥ 485 MPa | ≥ 275 MPa | 25 % |
Yes, Inconel 617 Bars/Rods are designed to perform exceptionally well in high-temperature environments up to 980°C.
Yes, they can be tailored in terms of size, dimensions, and specifications to meet specific industrial requirements.
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@sadikimetals.com
Inconel 617 Bars and Rods are widely utilized across aerospace, power generation, chemical processing, and petrochemical industries due to their remarkable high-temperature strength and oxidation resistance. They are particularly suited for creating turbine components, heat exchangers, furnace parts, valves, and high-temperature fasteners. In the energy sector, you’ll find them in gas turbines, steam turbines, and nuclear reactors, where extreme temperatures and stresses are the norm. Additionally, Inconel 617 Bars and Rods are essential in aerospace engine components, thermal processing equipment, and various industrial machinery.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Sadiki Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Kinshasa, Congo
