Super Duplex Steel Ferralium 255 Bars and Rods are prized for their remarkable blend of high strength, exceptional corrosion resistance, and impressive durability, especially in tough industrial and marine settings. Crafted with precision, these bars and rods offer outstanding mechanical stability, toughness, and reliability. Their ability to resist pitting, crevice corrosion, and stress corrosion cracking makes them perfect for critical applications where both structural integrity and performance are key. You’ll find Ferralium 255 Bars and Rods commonly used in the chemical, petrochemical, offshore, and marine industries, where demanding operations call for top-notch material performance.
These bars and rods are made from a high-alloy stainless steel that contains around 25–26% chromium, 6–7% nickel, and 4–5% molybdenum, along with trace amounts of nitrogen and other elements. This unique composition gives them excellent resistance to corrosion caused by chlorides and acidic environments, while also providing superior mechanical properties. In terms of mechanics, these bars and rods boast high tensile and yield strength, impressive toughness, and good ductility. Their combination of corrosion resistance and mechanical performance guarantees reliable and durable operation even under high pressure, elevated temperatures, and chemically aggressive conditions.
| Grade | Ferralium 255 |
|---|---|
| Specification | Super Duplex Steel Ferralium 255 Round Bar |
| Square bar size | 4 to 100mm |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Section | 3.0 to 12.0mm thickness |
| Round bar size | Diameter: 3-~800mm |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Billet Size | 1/2″ to 495mm Diameter | Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Condition | Hardened & tempered, annealed |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Technique | Ferralium 255 Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Form | Ferralium 2507 Round Bar, Rod, T-Bar, Super Duplex Steel Channel Bar, Precision Ground Bar, Super Duplex Steel Flat Bar, Super Duplex Steel Square Bar, Super Duplex Steel Blocks, Super Duplex Steel Round Rod, Super Duplex Steel Rings, Super Duplex Steel Hollow, Super Duplex Steel Triangle, Rectangle, Hex (A/F), Super Duplex Steel Threaded, Ferralium 2507 Half Round Bar, Profiles, Super Duplex Steel Billet, Super Duplex Steel Ingot, I/H Bar, Forging etc. |
| Mo | Cu | Cr | Ni | N | Si | Mn | W | P | S | C | Fe |
| 3.5 | 1.75 | 26 | 6.3 | 0.23 | 0.15 | 0.5 | 1 max | 0.025 max | 0.025 max | Balance | 0.005 max |
| Yield Strength (0.2%Offset) | MPa – 570-600 |
| Tensile Strength | MPa – 790 |
| Elongation | 25 % |
| STANDARD | UNS | DIN |
|---|---|---|
| Ferralium 2507 round bar | S32550 | 1.4507 |
Yes, Super Duplex Steel Ferralium 255 Bars can be welded using suitable techniques like TIG, MIG, or SMAW, ensuring precise heat input control to prevent phase imbalance. Pre-heating and post-weld heat treatments may be required for optimal weld integrity.
Super Duplex Steel Ferralium 255 Rods are highly resistant to galvanic corrosion due to their excellent corrosion resistance properties. However, they may still experience some susceptibility in highly corrosive environments when coupled with more anodic materials.
Super Duplex Steel Ferralium 255 rods are available in a wide range of sizes, typically from 3mm to 500mm in diameter. They are offered in finishes such as hot-rolled, cold-drawn, and polished for various applications.
Super Duplex Steel Ferralium 255 Bars and Rods find extensive use in chemical processing, marine applications, desalination, oil and gas, and other high-performance industrial settings. They’re perfect for making valves, flanges, pumps, pipe fittings, pressure vessels, and heat exchangers, where both corrosion resistance and high mechanical strength are essential. In offshore and chemical environments, they offer long-lasting reliability against seawater, chlorides, and acidic media. Plus, Ferralium 255 Bars and Rods are also utilized in specialized industrial applications, ensuring they meet the rigorous demands of various sectors.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
