Sadiki Metals is a reputable manufacturer and supplier of Titanium Grade 12 Bars and Rods, proudly based in Kinshasa, Congo. They’re well-known for providing high-performance titanium products that adhere to international quality standards. With a strong focus on precision and reliability, Sadiki Metals delivers products that boast excellent corrosion resistance, impressive strength, and durability even in the toughest environments. These bars and rods find their way into various industries, including chemical processing, marine engineering, power generation, and industrial fabrication. The company prioritizes consistent quality, timely delivery, and customer satisfaction, making them a trusted source for Titanium Grade 12 Bars and Rods in demanding applications.
Titanium Grade 12 Bars and Rods are primarily made of titanium, with added nickel (0.6–0.9%) and molybdenum (0.2–0.4%) to boost corrosion resistance and mechanical strength. This material stands out for its remarkable resistance to reducing acids, saltwater, and high temperatures. It has a tensile strength of around 483 MPa, good elongation, and exceptional weldability. This alloy maintains its structural integrity even under fluctuating temperatures and stress, making it perfect for harsh industrial applications that demand reliability and long-lasting performance.
| Standards : | ASTM B348, B863 / ASME SB348, SB863 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 12 | 3.7105 | R53400 |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
| Titanium Gr 9 | .08 max | .03 max | .25 max | .015 max | Bal | 0.30 max | – | .12 – .25 |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade 12 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Density | Melting Range | Modulus of Elasticity (Tension) | Specific Heat | Mean Coefficient of Expansion | Thermal conductivity | Electrical Resistivity |
| kg/m3 | °C | GPa | J/kg. °C | x10 -6 / °C | W / m. °C | micro-ohm.m |
| 4,507 | 1668± 10 | 103 | 519 | 8.41 | 11.4 | 0.420 |
| Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
| Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
| Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
| Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
| Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Grade 12 Titanium Bars Standard lengths of 2000 mm up to 6000 mm. Cut to size on request (tolerance +2/-0 mm).
| 5.0 | 45.0 |
| 6.0 | 50.0 |
| 7.0 | 55.0 |
| 8.0 | 60.0 |
| 9.0 | 65.0 |
| 10.0 | 70.0 |
| 12.0 | 75.0 |
| 16.0 | 80.0 |
| 20.0 | 90.0 |
| 25.0 | 100.0 |
| 30.0 | 130.0 |
| 35.0 | 160.0 |
| 40.0 | 200.0 |
Titanium Grade 12 offers excellent resistance to corrosion, especially in oxidizing and mildly reducing environments, and is highly durable in seawater and chemical processing conditions.
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@sadikimetals.com
Yes, Titanium Grade 12 exhibits remarkable high-temperature resistance, making it suitable for use in power generation and industrial processes that involve elevated temperatures.
You’ll find Titanium Grade 12 Bars and Rods in situations where corrosion resistance and durability are essential. They’re often used in chemical processing equipment, heat exchangers, and evaporators because of their ability to withstand acidic and saline environments. In marine engineering, they’re ideal for ship components and offshore structures that face seawater exposure. They also play a role in power plants for condenser tubing and high-temperature systems. Plus, they’re utilized in desalination plants and industrial piping systems. Their excellent weldability and strength make them a dependable choice for long-term use in highly demanding operational settings.
Titanium DIN 3.7105 Bars and Rods find extensive use in many industries requiring high-level corrosion resistance and tensile strength. These bars and rods are primarily found in chemical processing equipment, marine applications, heat exchangers, and desalination plants-they take the brunt of the harsh, corrosive environments. They are also used in power generation facilities for condenser tubing and in aerospace applications where lightweight, high-strength components are required. Chemical processing, marine engineering, power generation, aerospace and oil and gas are just a few of the significant sectors in which Titanium Grade 12 is used. Their weldability and durableness alone make them inseparable from all applications in extreme environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
